I am aware is is easy to setup a NAT bridging network interface (it is the default with incusbr0) and a macvlan network interface.
incusbr0 allows localhost access. macvlan allows LAN access but not localhost access
I would like to know what specific additional steps are required to add an incus network (and so interface), with any additional steps, to allow both localhost access and LAN from the same network interface.
I provide examples of specific steps required for incusbr0 and macvlan network interfaces at A friendly introduction to virtualising Virtualmin on Ubuntu with Incus - #2 by shoulders - Help! (Home for newbies) - Virtualmin Community. I have reproduced the original post in its entirety below.
To be clear, I am looking for the actual steps that I can test on setup below. I do not want to be referred to a link. Every link I have examined with regard to solving this type of issue has been a dead end for me. I also do not want to reuse or setup a libvirt interface.
The LAN interface name is enp3s0. Its ipv4 address is 192.168.20.17/24 and the gateway/DHCP server is at 192.168.20.1.
Thanks
John Heenan
REPRODUCED POST
Below are notes from setting up four incus instances of Ubuntu 24.04 on a physical server on a LAN, already running Ubuntu 24.04 desktop.
Two are container instances (not Docker) and two are virtual instances.
The container instances are one of a NAT setup and one of a LAN accessible macvlan setup
The virtual instances are also one of a NAT setup and one of a LAN accessible macvlan setup
A NAT setup instance can only be accessed in a regular manner from the localhost
A LAN accessible macvlan setup can be accessed from the LAN but not from the localhost. This is not a bug. It is designed into the Linux kernel.
So can an incus instance be accessed both from localhost and from the LAN? Not without a high level of unfriendly looking expertise that goes beyond the intended scope of providing a friendly introduction.
To keep with the friendly themes, setting up an incus web ui is included, but that is it, beacuse it is not necessary. When accessing the web ui, follow instructions on the web ui to either create a new certificate or use an existing one.
Webmin or Virtualmin, of themselves, should be OK in a pure Linux container. At least Virtualmin installs. If there are problems, it is likely due to utilities they use that are probably replaceable for utilities that do not call from user space into the kernel (which cannot be done from a container)
Most rented VPS won’t allow nested virtualization, so a container is likely necessary, if you want to try this on a VPS.
John Heenan
References:
Installing incus:
sudo su -
mkdir -p /etc/apt/keyrings/
curl -fsSL https://pkgs.zabbly.com/key.asc -o /etc/apt/keyrings/zabbly.asc
sh -c 'cat <<EOF > /etc/apt/sources.list.d/zabbly-incus-stable.sources
Enabled: yes
Types: deb
URIs: https://pkgs.zabbly.com/incus/stable
Suites: $(. /etc/os-release && echo ${VERSION_CODENAME})
Components: main
Architectures: $(dpkg --print-architecture)
Signed-By: /etc/apt/keyrings/zabbly.asc
EOF'
apt update
apt -y install incus
apt install incus-ui-canonical
apt -y install qemu-system # for qemu virtual instances managed by incus
echo "INCUS_UI=/opt/incus/ui" >> /etc/default/incus # or /etc/default/environment
Configuring incus:
# make a default profile with defaults
# for home LAN, only change from defaults was to make server available over the network (yes)
incus admin init
#Would you like to use clustering? (yes/no) [default=no]:
#Do you want to configure a new storage pool? (yes/no) [default=yes]:
#Name of the new storage pool [default=default]:
#Name of the storage backend to use (dir, lvm, lvmcluster) [default=dir]:
#Would you like to create a new local network bridge? (yes/no) [default=yes]:
#What should the new bridge be called? [default=incusbr0]:
#What IPv4 address should be used? (CIDR subnet notation, “auto” or “none”) [default=auto]:
#What IPv6 address should be used? (CIDR subnet notation, “auto” or “none”) [default=auto]:
#Would you like the server to be available over the network? (yes/no) [default=no]: yes
#Address to bind to (not including port) [default=all]:
#Port to bind to [default=8443]:
#Would you like stale cached images to be updated automatically? (yes/no) [default=yes]:
#Would you like a YAML "init" preseed to be printed? (yes/no) [default=no]:
# systemctl restart incus # if below does not work
# browse to https://hostname:8443
Installing two different types of Ubuntu instances, using NAT, from same image:
incus launch images:ubuntu/22.04 c1 # container
incus launch images:ubuntu/22.04 v1 --vm # virtual
incus list -cns4t
#+------+---------+------------------------+-----------------+
#| NAME | STATE | IPV4 | TYPE |
#+------+---------+------------------------+-----------------+
#| c1 | RUNNING | 10.79.158.18 (eth0) | CONTAINER |
#+------+---------+------------------------+-----------------+
#| v1 | RUNNING | 10.79.158.219 (enp5s0) | VIRTUAL-MACHINE |
#+------+---------+------------------------+-----------------+
Creating a macvlan interface and adding two more instances accessible from LAN
# add an incus macvlan network to allow access from LAN
ip address show
# choose an interface on LAN, such as enp3s0
incus network create macvlan --type=macvlan parent=enp3s0
incus launch images:ubuntu/22.04 mc1 -n macvlan # container
incus launch images:ubuntu/22.04 mv1 -n macvlan --vm # virtual
incus list -cns4t
#+------+---------+------------------------+-----------------+
#| NAME | STATE | IPV4 | TYPE |
#+------+---------+------------------------+-----------------+
#| c1 | RUNNING | 10.79.158.18 (eth0) | CONTAINER |
#+------+---------+------------------------+-----------------+
#| mc1 | RUNNING | 192.168.20.36 (eth0) | CONTAINER |
#+------+---------+------------------------+-----------------+
#| mv1 | RUNNING | 192.168.20.37 (enp5s0) | VIRTUAL-MACHINE |
#+------+---------+------------------------+-----------------+
#| v1 | RUNNING | 10.79.158.219 (enp5s0) | VIRTUAL-MACHINE |
#+------+---------+------------------------+-----------------+
Ping results:
sh -c 'cat <<EOF >> /etc/hosts
10.79.158.18 c1
192.168.20.36 mc1
192.168.20.37 mv1
10.79.158.219 v1
EOF'
#pinging results from localhost, as expected (not a bug)
ping c1 # ok
ping mc1 # fails
ping mv1 # fails
ping v1 # ok
#pinging from another pc on LAN, as expected (not a bug)
ping c1 # fails
ping mc1 # ok
ping mv1 # ok
ping v1 # fails
Accessing instances and force delting instances from localhost:
# access from localhost, note the gap between -- and bash
incus exec c1 -- bash
incus exec mc1 -- bash
incus exec mv1 -- bash
incus exec v1 -- bash
# forced deletion of instances from localhost
#incus delete c1 --force
#incus delete mc1 --force
#incus delete mv1 --force
#incus delete v1 --force
