How to limit network ingress and egress on a running container

LXD
1

I was trying to limit a container ingress as described from this external resource here:

lxc config device set mycontainer1 eth0 limits.ingress 1Mbit
Error: Device from profile(s) cannot be modified for individual instance. Override device or modify profile instead

Whats the proper way to rate-limit ingress and egress for my running container. This is related to the question here: Find network usage for a container

2

Change “set” to “override” in that command.

3
lxc config device override t1 eth0 limits.ingress 1Mbit
Error: No value found in "limits.ingress"

Still no luck?

4

What nic type is it?

5

eth0:
name: eth0
nictype: bridged
parent: br0
type: nic

6

Try

lxc config device override t1 eth0 limits.ingress=1Mbit

As that command allows overriding multiple keys at once (one per argument) and therefore requires key=value syntax for each argument.

7

This seemed to have effect!

lxc config device override t1 eth0 limits.ingress=1Mbit
Device eth0 overridden for t1

But if I try to set the egress now:

lxc config device override t1 eth0 limits.egress=1Mbit
Error: The device already exists

Do I need to set it all at once?

8

You can set both via the initial override command. But after the device is overridden (copied from the profile into the instance) you then need to use the “set” command.

1 Like
9

Right, thanx @tomp

If I edit the default profile with these limits, according to the docs, its applied automatically to all instances once changed.

Is this true, and/or do I need to restart the containers to get the rate limits to apply?

10

Thats right. The bandwidth limits can be applied without resetting the nic.

1 Like
11

But does a change to a profile (lets say the default) instantly / automatically gets applied aswell to all instances using it?

12

Yes

1 Like
13

Thanx for all the help @tomp ! This is what I ultimately did to limit networking capacity on LXD containers, as a reference for others. (Here is a link to the references on available limits for networking)

  1. First, I investigate the individual container. Note the “-e” which is needed to see any settings derived from the profiles as they are not shown otherwise:
lxc config show -e mycontainer
  1. If you need to modify the individual container, this is done in two steps. In the example below, we limit the container to 1Mbit both upload & download:
lxc config device override mycontainer eth0 limits.ingress=1Mbit
lxc config device set mycontainer eth0 limits.egress=1Mbit

No container restart needed. This comes into effect immediately. You can test this with the tool speedtest-cli

If you like to set this for all containers in the default profile, then:

Edit the profile:
lxc config profile edit default

Add limits.egress & limits.ingress to the device as below.

Note that the changes will take effect immediately for all containers using the default container without container restart needed.

config: {}
description: Default LXD profile
devices:
  eth0:
    limits.egress: 1Mbit
    limits.ingress: 1Mbit
    name: eth0
    nictype: bridged
    parent: br0
    type: nic
1 Like
14

Excellent, glad it worked out.

1 Like
15

This is very much needed and very helpful.

How would I enforce this also for “sub-projects”? I mean, is there a hierarchy to how these settings can be enforced so to protect the network from overload?

16

It doesn’t look like cumulative NIC limits are covered by project limits currently:

17

So, this would be needed to be set on all projects? How does an admin then enforce it for multiple clients using the same lxd-instance/cluster? I mean, it would be trivial to take down a complete environment just consuming all network capacity for any project.

18

You can’t at this time set per-project cumulative network limits for all instances within that project.

19

I understand. This would be a challenging situation then for multiple users/projects.

20

Sounds like a feature request :slight_smile:

1 Like
